How to extend the service life of fasteners?

2025-09-18 00:00:00

Fasteners, though small, are the "joints" and "bones" of industrial equipment and engineering structures. Their failure can lead to equipment downtime, performance degradation, and even serious safety accidents. Therefore, extending the service life of fasteners is not only related to economic benefits but is also crucial for ensuring safe and reliable operation. This is not achieved through a single measure but through a comprehensive lifecycle management process, from design and selection to installation, maintenance, monitoring, and replacement.

I. Precise Design and Correct Selection: Laying the Foundation for Longevity

Extending lifespan begins with the design phase; correct selection is fundamental to avoiding early failure.

1. Material Matching is Key: Fastener materials must be selected based on the application environment.

Strength and Toughness: In applications subject to dynamic loads and impact vibrations, materials with good toughness (such as alloy sTeel) should be selected to avoid simply pursuing high strength while ignoring the risk of brittleness.

Corrosion Resistance: In humid, chemically corrosive, or marine environments, carbon steel components are highly susceptible to corrosion, leading to reduced cross-section and stress concentration. Stainless steel (such as 304, 316), copper alloys, or higher-grade corrosion-resistant materials should be selected. For extreme environments, titanium alloys or nickel-based alloys can even be considered.

High and Low Temperatures: In high-temperature environments, creep of the material must be considered (e.g., alloy steel); in low-temperature environments, toughness is paramount (to prevent brittleness), and austenitic stainless steel or special alloys are typically chosen.

2. Specification and Performance Grade Matching: It is essential to ensure that the strength grade of the fasteners (e.g., bolts grade 8.8, 10.9) can withstand the design preload and working load, with sufficient safety margin. Choosing an inappropriate low-grade bolt can cause overload yielding, while blindly choosing an excessively high grade can be costly and detrimental to toughness.

3. Surface Treatment and Coating: A Critical Barrier: Surface treatment is one of the most economical and effective means of isolating corrosive media and extending service life.

Zinc Plating: Common and relatively inexpensive, providing basic cathodic protection. However, the risk of hydrogen embrittlement needs to be considered (this can be eliminated by baking to remove hydrogen).

Dacromet: Excellent corrosion resistance, no hydrogen embrittlement issues, widely used in automotive and rail transportation.

Phosphating: Offers a good coefficient of friction and is often used in conjunction with oiling for internal parts such as engines.

Hot-dip galvanizing: Provides a thick coating and extremely long corrosion resistance; commonly used for outdoor structures such as power towers and bridges.

II. Scientific Installation and Precise Pre-tightening: Key to Effectiveness

Statistics show that over 50% of fastener failures are caused by improper installation and pre-tightening force control.

1. Torque and Pre-tightening Force Management: Pre-tightening force is fundamental to bolted connections. Excessive torque can cause bolt elongation or even breakage; insufficient torque will loosen the connection and lead to failure under vibration.

Use a torque wrench: Always use a calibrated torque wrench; avoid relying on feel or ordinary wrenches.

Follow torque standards: Tighten strictly according to the torque values specified in the design.

Consider the coefficient of friction: The vast majority of torque (approximately 90%) is used to overcome the friction between the bolt head and the nut bearing surfaces. Therefore, a stable coefficient of friction is crucial; ensure clean threads and use an appropriate lubricant (such as torque paste).

2. Advanced Tightening Processes: For critical connections, more precise control methods can be employed.

Torque-Angle Method: An initial torque is applied to eliminate gaps, then the nut is rotated at a specific angle, allowing for more precise control of bolt elongation and preload.

Hydraulic Tensioning: Using a hydraulic tensioner, bolts are directly stretched to the predetermined length, resulting in extremely high installation accuracy, suitable for large, critical connections.

3. Correct Installation Sequence: For connections with multiple bolts, such as Flanges, the principle of cross-symmetry and step-by-step tightening must be followed (usually in three steps: initial tightening, secondary tightening, and final tightening) to ensure uniform stress on the gaskets, reliable sealing, and to avoid failure due to uneven loading.

III. Continuous Maintenance and Condition Monitoring: Guarantee of Dynamic Management

Installation is not a one-time event; continuous maintenance and monitoring are necessary to address environmental changes and performance degradation.

1. Regular Inspection and Retightening: During the initial operation of the equipment, preload may decrease due to vibration, settlement, and creep. Regular inspections and retightening of critical bolts should be performed according to a schedule after a period of operation. 2. Corrosion Prevention and Cleaning: Regularly clean dirt, water, and corrosion products around fasteners, keeping them dry and clean. For fasteners used outdoors or in harsh environments, regularly inspect and reapply anti-corrosion coatings (such as paint).

3. Condition Monitoring Technology Applications:

Visual Inspection: Inspect for obvious rust, deformation, and cracks.

Ultrasonic Testing: Use an ultrasonic force gauge to directly measure the preload inside the bolt for precise monitoring.

Acoustic Emission Technology: Can be used to monitor the initiation and propagation of cracks.

IV. Timely Replacement and Disposal

Every part has a design life. Fasteners should be replaced immediately when the following conditions occur; never reuse or force them to continue operating:

Thread damage, tensile deformation, or cracks.

Corrosion exceeding permissible standards, or a significant reduction in shank diameter.

Severe wear or head structure failure.

For applications with clearly defined service life requirements (such as aviation and racing), a mandatory replacement policy must be strictly enforced.

In summary, extending the service life of fasteners is a systematic project that spans the entire process from conceptual design, procurement, installation, and operation and maintenance. It requires engineers and technicians to possess comprehensive knowledge, considering multiple dimensions such as materials science, mechanical design, tribology, and corrosion protection. Only through a closed-loop management system of correct selection, scientific installation, diligent maintenance, and timely replacement can the potential of these "industrial millet" fasteners be maximized, providing a solid guarantee for the safe, stable, and long-term operation of equipment and structures.
